電機型號 TYPE |
額定電壓 VDC |
額定電流 mA |
空載轉速 r/min |
空載電流 mA |
額定轉速 r/min |
額定轉矩 mM.m |
輸出功率 W |
堵轉力矩 mN.m |
堵轉電流 A |
| 4568 | 24 | 350 | 2000 | 0.18 | 1700 | 30 | 5 | 0.12 | 1.1 |
| 4568 | 24 | 800 | 3000 | 0.25 | 2400 | 43 | 10 | 176 | 2.7 |
| 4568 | 24 | 100 | 4000 | 0.35 | 3200 | 43 | 14 | 215 | 3 |
| 3540 1230 |
減速比 R |
3.7 | 5.2 | 14 | 19 | 27 | 51 | 71 | 100 | 139 | 189 | 264 | 369 | 516 | 720 |
| 空載轉速 r/min |
539 | 386 | 143 | 105 | 74 | 39 | 28 | 20 | 14 | 11 | 7.6 | 5.4 | 3.9 | 2.8 | |
| 額定轉速 r/min |
458 | 328 | 121 | 89 | 63 | 33 | 24 | 17 | 12 | 9 | 6.4 | 4.6 | 3.3 | 2.5 | |
| 額定轉距 Nm |
0.1 | 0.14 | 0.34 | 0.46 | 0.66 | 1.1 | 1.6 | 2.2 | 3 | 3.7 | 5.1 | 7.2 | 10 | 10 | |
| 較大瞬間允許負載 Nm |
3 | 3 | 12 | 12 | 12 | 25 | 25 | 25 | 25 | 30 | 30 | 30 | 30 | 30 | |
| 3540 1240 |
空載轉速 r/min |
809 | 579 | 214 | 158 | 111 | 59 | 42 | 30 | 22 | 16 | 11 | 8.1 | 5.8 | 4.2 |
| 額定轉速 r/min |
647 | 463 | 171 | 126 | 89 | 47 | 34 | 24 | 17 | 13 | 9.5 | 6.5 | 4.7 | 3.3 | |
| 額定轉距 Nm |
0.23 | 0.33 | 0.79 | 1.1 | 1.5 | 2.6 | 3.6 | 5.1 | 7.1 | 8.6 | 10 | 10 | 10 | 10 | |
| 較大瞬間允許負載 Nm |
3 | 3 | 12 | 12 | 12 | 25 | 25 | 25 | 25 | 30 | 30 | 30 | 30 | 30 | |
| 35400 1250 |
空載轉速 r/min |
1080 | 770 | 285 | 210 | 148 | 78 | 56 | 40 | 28 | 21 | 15 | 10 | 7.8 | 5.6 |
| 額定轉速 r/min |
862 | 617 | 228 | 168 | 118 | 62 | 45 | 32 | 24 | 17 | 12 | 8.7 | 5.8 | 4.4 | |
| 額定轉距 Nm |
0.15 | 0.2 | 0.54 | 0.73 | 1 | 1.6 | 2.6 | 3.6 | 5 | 6.5 | 9.2 | 10 | 10 | 10 | |
| 較大瞬間允許負載 Nm |
3 | 3 | 12 | 12 | 12 | 25 | 25 | 25 | 25 | 30 | 30 | 30 | 30 | 30 | |
| 減速器長度 mm |
35.3 | 45.6 | 58.4 | 68.7 | |||||||||||
| 減速級數(shù) | 1 | 2 | 3 | 4 | |||||||||||
